Worm Gearbox (NMRV)
An NMRV-series worm gearbox in a light, corrosion-resistant die-cast aluminium body. It provides very high reduction ratios in a compact footprint, with self-locking behaviour at the higher ratios.
Ideal for conveyors, warehouse doors, mixers and any application needing large reduction in limited space.
Technical Specifications
| Ratio | 1:5 to 1:100 |
|---|---|
| Frame Sizes | NMRV 030 – NMRV 150 |
| Input Power | 0.06 – 15 kW |
| Output Torque | Up to 1,700 N·m |
| Housing | Die-cast aluminium |
| Worm Wheel | Bronze |
| Self-Locking | Available at high ratios |
Key Features
- High reduction ratios in a small package
- Light, corrosion-resistant aluminium body
- Self-locking at high ratios
- Multiple mounting orientations
- Direct motor mount or input shaft
Catalogue & Downloads
To view the catalogue on mobile, use the download button above.
